ALBY 51
180W/200WLED Highbay luminaire, in die cast aluminium housing. Luminaire has been dsigned to illuminate large areas. Suitable for very high level stacking areas. It’s environment friendly, and available in glass and IP Lens version.
LED Highbay luminaire, in die cast aluminium housing. Luminaire has been dsigned to illuminate large areas. Suitable for very high level stacking areas. It’s environment friendly, and available in glass and IP Lens version.
| (IS)Wattage | Input Voltage (V) | Frequency (HZ) | Operating Voltage Range (V) | Current (A) @ 240V | Power Factor | Driver Efficiency | External Surge | |
|---|---|---|---|---|---|---|---|---|
| ALBY 51-180W(57)LP | 180W±10% | 240 | 50 | 140 - 305 | 0.675 - 0.825 | ≥0.95 | >85% | 10 KV |
| ALBY 51-200W(57)LP | 200W±10% | 240 | 50 | 140 - 305 | 0.750 - 0.916 | ≥0.95 | >85% | 10 KV |
| CRI | ≥ 70 |
| Ingress Protection | IP 66 |
| Operating Temperature | (-)10°C to (+)50°C |
| Colour Temperature | 5700 K (Typical) |
| Beam Angle | Integrated lens plate 60° and 90° |
| External Surge | 10KV-5KA |
| IK Rating | IK-07 (For Higher IK Please Contact ) |
